Universal pole bracket UPB-1

Description

The UPB-1 bracket is manufactured from aluminum alloy with correspondingly high mechanical strength. Its unique patented design has been developed to propose a universal fitting covering all installation situations on wooden, metal or concrete poles :

Suspension of running out rollers  
Stay systems  
Cross-arm installation  
Dead-ending of single, double or triple parallel lines.  
Dead-ending of several drop wires.  
Jointing points 
Angle points 
Derivation points

SPECIFICATION
MESSAGE

Product Type

Material

MBL,KN

Weight,kg

UPB-1

Aluminum

5KN

41*41*26cm,50PCS

Installation
  With steel bands The UPB-1bracket can be installed on any type of pole – drilled or undrilled – with two 20x0.7 mm stainless steel bands C201 plus two buckles HC-20-T (check our pole banding products). Usually allow two bands of one meter each per bracket.  With bolts If the top of the pole is drilled (wooden poles, occasionally concrete poles) the UPB-1bracket can also be secured with bolt. The bolt length should be at least equal to the pole diameter + 50 mm (bracket thickness). Check our bolts.
