Suspension Bracket, PS-1500

Description

The PS-1500 bracket is manufactured from aluminum alloy. It’s developed to tension or suspend fiber optic cable clamps with all installation situations on wooden, metal or concrete poles :

Suspension of running out rollers  
Stay systems  
Cross-arm installation  
Dead-ending of single, double or triple parallel lines.  
Dead-ending of several drop wires.

SPECIFICATION
MESSAGE

Product Type

Material

MBL,KN

Weight,kg

PS-1500

8

Aluminum

31*31*27cm,100pcs/carton

Installation
  With steel bands The PS-1500 bracket can be installed on any type of pole – drilled or undrilled – with two 20x0.7 mm stainless steel bands C201 plus two buckles HC-20-T (check our pole banding products). Usually allow two bands of one meter each per bracket.  
With bolts If the top of the pole is drilled (wooden poles, occasionally concrete poles) the PS-1500 bracket can also be secured with bolt. The bolt length should be at least equal to the pole diameter + 50 mm (bracket thickness).
